| Sensor size | 934x582 pixel |
| Image sensor size | ¼-type Super HAD CCD II |
| Image sensor | CMOS |
| Min illumination/ light sensitivity | 0.6 lux at F1.6, 1/50s and 50 IRE |
| Max video resolution | PAL |
| Max frames per second | 50 |
| Focal length | 3 - 122 mm |
| Angle of view | Wide: 60° Tele: 1.6° |
| Aperture (F) | 1.6-4.6 |
| Focus | Auto |
| Optical zoom | 40 x |
| Gamma Radiation Tolerance (min) | 1000 Gray |
| Gamma Radiation Dose Rate (min) | 100 Gray/h |
Radiation Tolerant Cameras
RADCAM Æsir
Fixed, small and lightweight with 40x zoom
- High quality color imaging
- Lightweight (2.4kg)
- Powerful 40x optical zoom
- TID > 1000 Gy
- Dose rate: 100 Gy/h
- Radiation exposure Sensors
Product overview
The RADCAM® ÆSIR, ISEC’S newly developed analog camera for radioactive areas made for analog infrastructure. This unique analog radiation hardened camera is specially designed for existing nuclear analog systems. It is fixed, small and lightweight with 40x optical zoom capabilities.
Key features
- High quality color imaging
- Very compact and robust design
- Lightweight (2.4 kg)
- Powerful 40x optical zoom
- TID > 1000 Gy
- Dose rate: 100 Gy/h
- Low and high temperatures (-25°C to 60°C)
- Simple Cabling Coax + Power supply + RS-485
- IP65 housing
- Radiation Exposure sensors
Documents
Areas of application
Pressure Water Reactor
- Emergency response
- Special surveillance
applications - Long range surveillance
- Upgrade of existing
Pan-Tilt outstation
Boiling Water Reactor
- Emergency response
- Special surveillance
applications - Long range surveillance
- Upgrade of existing
Pan-Tilt outstation
Heavy Water Reactor
- Emergency response
- Special surveillance
applications - Long range surveillance
- Upgrade of existing
Pan-Tilt outstation
Nuclear Back-End
- Emergency response
- Special surveillance
applications - Long range surveillance
- Upgrade of existing
Pan-Tilt outstation
